LY-7506 GROWIN
Products
Overview
- Aluminum framework
- Adjustable seat depthh and height
- Adjustable seat width: 12”, 13”, 14”, 15"
- Adjustable backrest straps
- Detachable & height adjustable PU armrest
- ABS side panel
- Detachable swing away footrest
- Two pieces footplate with calf strap
- 3 cm seat cushion
- Front castor: 6” x 1-1/4" PU tire
- Rear wheel: 22” x 1-3/8" PU tire
- Camber angle: 0°, 3°
- Max. capacity: 100 kg
feature
-
Tension-adjustable straps -
Height adjustable push handles -
22" Rear wheel with quick release axle -
Detachable armrest -
Height adjustable armrest -
Detachable swing away footrest -
Compact size for transportation -
Calf strap
Measurement
| Seat width adjustable | 12", 13", 14", 15" | |
| Seat height adjustable | 420 mm, 440 mm, 460 mm | |
| Seat depth adjustable | 360 mm, 385 mm, 410 mm | |
| Center of gravity adjustable | 70 mm | |
| Push handle height adjustable | 120 mm in 6 sections | |
| Seat front to footplate distance adjustable | 290 mm ~ 410 mm (120 mm in 8 sections) | |
| Rear wheel camber optional | 0゜, 3゜ |
